Vertical Multistage Pumps - MTP Series
The C.R.I MTP Series vertical multistage pumps are high-efficiency solutions engineered for demanding high-pressure applications. Built for durability, the MTP Series features major components made from corrosion-resistant stainless steel and high-strength engineering polymers, ensuring robust construction for harsh operating conditions while maintaining superior hydraulic efficiency.
Each pump is equipped with a premium efficiency motor, contributing to energy savings and reliable long-term performance. The MTP Series is an ideal choice for industrial and commercial water supply systems where consistent high pressure is essential.
Applications
- Domestic and industrial pressure boosting systems
- High-pressure industrial applications
- Utility water supply in industries and commercial buildings
- Jockey pumps in firefighting systems
- Industrial washing and cleaning systems
- Car washing systems
Key Features
- High efficiency
- Stainless steel impeller
- Flangeless threaded port design
- ED coated cast iron pump parts
- Equipped with premium efficiency motors
All you need to know about - Vertical Multistage Pumps - MTP Series
Specifications
| Power Range | 0.55 – 2.2 kW |
| Speed | 2850 rpm |
| Head Range | 25 – 211m |
| Flow Range | 1 – 4m³/h |
| Versions | Single Phase: 220–230V, 50Hz A.C. | Three Phase: 380–415V, 50Hz A.C. |
| Degree of Protection | IP55 |
| Class of Insulation | F |
| Duty Type | S1 (Continuous) |
| Shaft Seal | Mechanical Seal |
| Maximum Liquid Temperature | -10°C to 40°C |
| Maximum Ambient Temperature | 40°C |
| Maximum Operating Pressure | 21 bar |
| Flange Standard | DIN |
| Suction and Delivery Size | 1″ |
| Material of Construction (MOC) | Stainless Steel & High-Strength Engineering Polymers |
