Self-priming / Non-self priming monoblock pumps (Mini Pumps)
ELSA PRO / ELSA / MIKI / DORA / SHINE / XCITE / ROYALE PRIDE / ROYALE / DHOOM / CHAMPEE Series
C.R.I. “SMB Series” Self-priming non-Clog Monoblock Pump’s are especially designed to dewater the sewage and sludges
from trenches and pits. It is designed with non-clogging semi open type impellers which is supports for handling suspended
solids. These pumps are powered by a totally enclosed fan cooled A.C. induction motor. Motor stator is made of low watt
loss silicon steel laminations assembled under pressure and rigidly locked in the frame. Construction of motor frames and
usage of quality materials result in high performance and low temperature rise thereby increasing the life cycle of the motor.
Applications
- Pumping from Septic tanks in all types of Industries.
- Draining sewage / Rain water from hotels, malls & commercial buildings.
- Water recycling plants.
- Pumping waste water in Tunnels & Mines.
Key Features
- Non clogging impellers ensures free flow of solids.
- Solid Handling capacity upto 15.5mm.
- Quick automatic Self-priming function-no need for footvalve.
- Back-pull out type for easy maintenance.
- Efficient pumps with more energy savings.
All you need to know about - Self-priming / Non-self priming monoblock pumps
Specifications
| Power range | 0.37 kW – 1.1 kW (0.5HP – 1.5HP) |
| Speed | 2880 RPM |
| Versions | Single Phase 220-240 V, 50 Hz AC supply |
| Maximum total head | 100 metres |
| Maximum flow rate | 4500 LPH (4.5 m³/hr) |
| Maximum suction lift | Upto 8 metres |
| Nominal size (suction x delivery) | 15×15 & 25×25 mm |
Material Of Construction - Pump
| Pump Casing | Cast Iron | Motor Shaft | SS 410 |
| Bracket & Rear Cover | Cast Iron / Aluminium | Cooling Fan | Poly Propylene – Co Polymer |
| Volute Casing | Forged SS / Brass | Cooling Fan Cover | Poly Propylene – Co Polymer / MS |
| Rotor | Aluminium Die Cast | Impeller | High Tensile Brass |
| Motor Body | Aluminium Extruded / Die Cast / Cast Iron | Mechanical Seal | Carbon & Ceramic |
